6.5 inch midrang speaker professional audio speaker pa speaker 6.5

Name: 65 inch midrang speaker professional audio speaker pa speaker 65
Brand: HYYX
Price: 15.00 USD

China 6.5 inch midrang speaker professional audio speaker pa speaker 6.5 wholesale

Place of Origin : Guangdong, China

Brand Name : HYYX

Model Number : HYW-650-025

Certification : ce

Supply Ability : 10000 Piece/Pieces per Week

Packaging Details : 1. Inside + outside strong double boxes 2. Customized

MOQ : 10 Piece/Pieces

Price : $15.00 - $22.00 / Piece

Warranty : 3months-1year

Customized : yes

Dimension : 6.5 inch

Power Supply Mode : other

Storage : NO

SNR : NO

Output Power : NO

Connection Type : other

Shell Material : metal

Format : NO

The body material : metal

radio function : no

Product Name : 6.5 inch midrange speaker

Sensitivity : 93dB

Frequency Response : 100Hz-5KHz

Nominal Impedance : 8 ohm / 4ohm

Size : 8/10/12/15/18/21 Inch Optional

Rated Power : 200W

Cone material : Paper

Surround material : Cloth

Magnet material : Ferrite

Voice coil diameter : 50mm/2 inch

Port : Huangpu, Nansha

Contact Now

Product Description

6.5 inch midrang speaker professional audio speaker pa speaker 6.5

Specification

Features :

_{- 6.5 inch midrange speakers for professional audio}

_{- 93dB sensitivity 1W/1M}

_{- 200W RMS , 500W Max power handling}

_{- 100hz-5khz Frequency response}

_{- Ferrite magnet}

_{- 2 inch/ 50mm copper voice coil}

Speccification :

Specification
Nominal diameter	160/6.5	mm/inch
Nominal impedance	8/4	ohm
Min impedance	5.2/3.6	ohm
Frequency response	100-5k	Hz
Magnet material	Ferrite
Sensitivity (1w/1m)	93	dB
RMS power handling	200	Watts
Continuous power handling	400	Watts
Voice coil diameter	50/2	mm/ inch
Winding material	Copper
Cone material	Paper
Surround material	Cloth
T/S Parameter
Fs	92.5	Hz
Re	5.2	Ω
Qes	0.69
Qts	0.62
Qms	6.16
Vas	3.4	L
Rms	2.2	kg/s
Cms	0.12	mm/N
Mms	20.8	gr
BI	10.6	N/A
Rp	41.4	Ω
Lp	11.0	mH
Cp	367.1	uF
Le	0.5	mH
Xmax	6	mm
Mounting information
Overall diameter	162/6.4	mm/inch
Bolt Circle diameter	121/4.88	mm/inch
Baffle Cutout diameter	145/5.7	mm/inch
Depth	86/3.38	mm/inch
Flange thickness	8/0.31	mm/inch
Shipping information
Net weight	2.6KG	KG
Shipping weight	3.2KG	KG
Shipping box	200x200x110	mm
